50MM DMX LED Pixel Light

Product Name: 50MM DMX LED Pixel Light

Facebook youtube  skype


    1, 30mm, 50mm, 100mm, and 120mm diameter are available.
    2, The pixel with milky/clear/ frosted cover available.
    3, DC 12V / DC 24V input.
    4, IP65 waterproof.
    5, 44 Frame/second.
    6, DMX address setting manually or automatically.
    7, Easy control by DMX SD card control, Online Venus 8/16, DVI control.
    8, Easy to install.
Parameters Description
Model NO. LWS-RGBD30-DMX-12V0301  LWS-RGBD50-DMX-12V0301  LWS-RGBD100-DMX-24V1201 LWS-RGBD120-DMX-24V1801
LED Chip SMD RGB 5050 SMD RGB 5050 SMD RGB 5050 SMD RGB 5050
LED QTY 3 pcs 3 pcs 12 pcs 18 pcs
Emitting Angle 120 degrees 120 degrees 120 degrees 120 degrees
Color RGB full color RGB full color  RGB full color RGB full color
Gray Scale 256 256 256 256
Operating Voltage DC 12V DC 12V DC 24V DC 24V
Power MAX=0.72W MAX=0.72W MAX=2.88W MAX=4.32W
Control Protocol DMX512 DMX512 DMX512 DMX512
Dimension 30MM diameter 50MM diameter 100MM diameter 120MM diameter
Base Material N/A ABS PC/ Aluminum PC/ Aluminum
Protection IP65
LED Source Life 50,000 hours, based on test data of LED manufacturer
Temperature -4℉ to 122℉(-20℃ to 50℃) operating temperature
Humidity Range 0 to 95% non-condensing
Installation M3*25mm screw with 29mm length expansion bolts
